REFERENCE DESIGN
IRMCS2031
Shunt Resistor and Current Rating
Two 20m Ohms current sensing shunt resistors are equipped as default resistors at factory shipment (R34 and R36
located on the bottom side of PCB). With these resistors, IRMCS2031 can deliver up to ± 13A maximum peak
current to the motor including overshoot of current regulation.
When using any higher power motor with a rating greater than 3Arms and less than 6Arms continuous current, then
10m Ohm shunt resistors are recommended in place of the 20m Ohm shunt resistors.
This document is the property of International Rectifier and may not be copied or distributed without expressed consent.
10
